8MP Face Detection VCA AI Human & Vehicle Detection Dual Light PoE Bullet IP Camera

1/2.8" Sony CMOS

4K resolution 3840 x 2160P

Face Detection,Human&Vehicle Detection, Line Crossing, Area Entry/Leaving Detection, Area Intrusion Detection

Low illumination 0.01Lux

Day/Night, AWB/MWB, 2D/3D-DNR

WDR,Motion Detection, Privacy Mask,Image Mirror,ROI

RTSP and Onvif 23.12 Compatible

H.265/ H.264 Dual-stream Media Server

Easy-to-use P2P Cloud Service

Multi web browser, PC Client, Mobile APP, Remote access

RJ45 100mbps Network Port, IEEE802.3af PoE

Lightning Protection 4000V

Strong Water-proof Housing, IP67

2pcs IR & Warm Dual Lights，Light Distance:20-30M

Warm Light on and Colorful Imaging When Detect Human Body or Vehicle

2.8mm F1.6 Fixed Lens

Internal Microphone

SD Slot optional

Download PDF

Tech Specs

Details

Video

Model	N798BADZ49EA
Camera
Image Sensor	1/2.8" 8MP Sony IMX415 CMOS
Soc Chip	Sigmastar SSC378DE
Effective Pixels	3840(H)×2160 (V)
Exposure Shutter	AUTO/Manual: 1/10s ~ 1/8000s, Max Shutter speed adjustable
Day/Night	Auto(Active/passive/schedule)/Day/Night, switch threshold, sensitivity, anti-flicker(Auto/50Hz/60Hz)
Image Adjust	Brightness,Saturation,Sharpness,Contrast,Denoise (0-100%) adjustable
White Balance	AWB/MWB
WDR	Yes
Light Mode	Smart(dual-light) / IR / White light, adjustable
Light Control	Auto/Manual, Brightness level (0-100%) adjustable
DNR	2D/3D DNR
Encode
Video Standard	H.264/H.265
Video Resolution	Main Stream:
	20fps@8MP(3840x2160)(default),30fps@6MP(3072x2048)/5MP(2592x1944)/4MP(2560x1440)/3MP(2304x1296)/1080P/720P
	Sub stream: 10fps@720P,30fps@D1(704x576)(default)/(720x480)/VGA(640x480)/QVGA(640x360)
Video Bitrates	Main stream: 64kbps-8Mbps
	Sub stream: 64kbps-2048kbps
	VBR/CBR , quality(1-9), GOP(1-128)
Image Snapshot	Sub Stream(SD) snapshot
Image Rotation	0 / 90 / 180 / 270 degree adjustable
Border Crop	X crop, Y crop
Image Mirror	horizon / vertical / horizon&vertical adjustable
OSD Overlay	Font size(1-4), position,Time, Title, AM/PM, Color, User OSD, Alarm OSD
Privacy Mask	4 areas
Region of Interest	ROI: Each stream support 8 areas
Audio Standard	G.711-u/G.711-a/AAC/PCM, AEC
Built-in Mic	Yes
LED and Distance
LEDs	2pcs IR & Warm Dual Lights
Light Distance	20-30M
Lens
Focal length	2.8mm F1.6 Fixed Lens
Language
English, simplified Chinese, Chinese Traditional, Japanese, Korean, German, Polish, Italian, Turkish, Ukraine, Russian, etc.
Smart Detection
Motion Detection	Yes
Digital IO Alarm	1 pair Alarm-in/Alarm-out, normally open/normally close (optional)
Human Vehicle Detection	Yes, (2-20 meters)
Cross Line Detection	Yes, 4 lines
Perimeter protection	Yes, 4 areas
Face Detection	Yes, (1-5 meters)
Target Detection Type	Human Shape, vehicle, non-motor vehicle, Pet, Face (12px-1000px)
Trigger Action Linkage	Snapshot, Record, Relay optional, White LED Flash, Email, FTP, NAS storage (NFS)
Simultaneous Detection	Maximum 16 targets simultaneous detection
Storage Type	Schedule/Trigger: Email, FTP, NAS(NFS)
Network Services
Protocol	HTTP(s)/RTSP/FTP/SMTP/DHCP/NTP/DST/RTP/RTMP/P2P/HiK/IPv4/IPv6/NFS/DDNS
IP Address Filtering	Yes (Allow list, Deny list)
P2P Mobile APP	Android, IOS
Web Access	IE, Firefox, Chrome, Edge, Safari, etc.
Web Access	(Windows/Linux/Mac/Chromebook/Tablet/Mobile phone)
PC Tool	Windows, Mac
ONVIF	23.12 compatible (profile S G T M)
General
Network Port	1-RJ45, 100Mbps, POE(IEEE802.3af)
Power Supply	12 VDC ± 10%
Power Consumption	< 8 W
Operating Temp.	-20℃-(+60)℃, 10%-90%RH

How does Network
IP Camera Work?

IP Camera connect directly to the network,with H.265 compressed technology to save the space and bandwidth. It can be remotely viewing in realtime and back up with high quality high definition 4K,5MP,2MP image or video with audio via any PC,Recorder and mobile app to secure people and world safe.
